| 브랜드 이름: | TICO |
| 모델 번호: | STC-CFX-5C |
| 모크: | 1세트 |
| 가격: | 협상 가능 |
| 배달 시간: | 15 ~ 20 근무일 |
| 지불 조건: | 티/티 |
5 Channels 18650 Cylindrical Cell Sorting Machine
Brief Introduction
18650 Cylindrical cell sorting machine is used for sorting 18650 battery grade by testing battery internal resistance and voltage, which is equipped with high precision internal resistance & voltage testing system. It is designed with 5 channels ,4 OK channels + 1 NG channel, which can sort the battery grade precisely according to the preset value.
Key Features
• Sorting the battery internal resistance and voltage automatically.
• Multi channels design, 4“OK” and 1 “NG” channels.
• Equipped with high precision internal resistance and voltage test system, the cell will be accurately delivered to the related channels according to preset value.
• Rapid sorting and high production efficiency.
• It owns the universal wheel, convenient to move.
Technical Parameters
| Model | STC-CFX-5C |
| Voltage | AC220V±10%, 50Hz |
| Application | 18650 Cylindrical battery |
| Sorting channel | 5 channels |
| Power | ≤1000w |
| Accuracy |
Voltage: 0.01mV as standard, 0.001mV is optional Internal resistance: 0.01mΩ as standard, 0.001mΩ is optional |
| Working temperature | 25℃±5℃ |
| Humidity | ≤85% |
| Working surroundings | No pollution, and no stronger EMI |
| Compressed air | 0.5~0.7MPa |
| Damage rate of product | ≤0.1% |
| Efficiency | ≥60PPM |
| Failure rate of product | ≤ 2% |
| Dimension | L1100 * W620 * H1400mm |
| Weight | 180kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 Year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes, most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
