| 브랜드 이름: | TICO |
| 모델 번호: | STC-DYG-200F |
| 모크: | 1세트 |
| 가격: | 협상 가능 |
| 배달 시간: | 20~30일 |
| 지불 조건: | 티/티 |
Split Type Hydraulic Calender Machine
Product Introduction
The equipment is designed for high-precision rolling of cathode and anode electrodes in the battery industry. It provides excellent uniformity in both the transverse and longitudinal directions. The processed electrodes feature superior surface quality and are suitable for applications requiring high consistency in rolling force and gap.
Key Features
● The equipment can be placed inside a glove box for use.
● Integral gantry frame, CNC precision processing to ensure high accuracy and stability.
● Rollers are manufactured from imported cold-rolling alloy steel and undergo heat treatment, surface chrome plating, and deep cryogenic treatment, resulting in high hardness and excellent wear resistance.
● Patented hydraulic calendering mechanism ensures stable pressure and excellent rolling uniformity in both transverse and longitudinal directions.
● Inclined roller-gap adjustment device with digital dial indicator display.
● PLC and HMI operation, convenient to set each parameter.
● The surface of the rollers is treated with hard chrome plating, providing excellent rust resistance and easy maintenance.
● Optional unwinding and winding system available for continuous roll-to-roll calendering operation.
Technical Parameter
| Model | STC-DYG-200F |
| Voltage | AC220V±10% |
| Total power | 2KW |
| Roll pressing speed | 0.3 ~ 4m/min |
| Roller size | Φ200mm*W200mm |
| Substrate width | Max 180mm |
| Roll pressing gap | 0~2mm adjustable |
| Dial indicator | Digital dial indicator displays the gap, accuracy 0.001mm |
| Dimension |
Electric unit: L800 mm × W550 mm × H600 mm |
| Weight | 450kg |
Warranty
1 year warranty with lifetime support. Man-made damage is not covered.
FAQ
1. Are you a manufacturer?
A: Yes, our factory is located in Shenzhen, China.
We have more than 10 year experience for manufacturing battery lab research equipment. We own a professional R&D department.
2. Do you accept customized product?
A: Yes. Most of our products can be customized to meet different requirements.
3. Will you provide test video before dispatch?
A: Yes, we take test video for every equipment before dispatch, which will display how to use it.
4. Can you offer overseas installation service?
A: Yes, we can dispatch professional engineer for on-site installation service.
